Bowers & Wilkins CCM632 – In Ceiling Speaker
Bowers & Wilkins
$350.00
(No reviews yet)
Write a Review
Bowers & Wilkins
Bowers & Wilkins CCM632 – In Ceiling Speaker
See nothing, hear everything
In-ceiling speakers, designed to squeeze into small spaces or be used in multiples for diffuse, background sound, are really difficult to get right. If the driver’s too small, there won’t be enough bass without adding a bulky subwoofer, but the common alternative is a 2-way where the tweeter sits in front of a small bass/midrange driver. The problem with these is the driver fires around the tweeter’s body, inevitably leading to colouration. The new Bowers & Wilkins CCM632 is a single 75mm (3inch) full-range driver with a beautifully well-balanced sound, that sidesteps traditional small speaker issues yet still takes up less than 150mm (6”) diameter space installed. The CCM632 also features Bowers & Wilkins new and innovative ZipDogs™ fixing method. These make short work of installation and cope with almost any thickness of mounting panel. Each speaker comes with an integral enclosure to minimise acoustic bleed into adjoining spaces. Speakers are supplied in pairs, with each pack including round and square magnetically fixed, and fully customisable, grille/bezel assemblies.
Best Used in Pairs for Single Stereo (L/R) Zones or as Dolby Atmos Height Channels in CI Home Theaters
Performance Series
Incorporating QuickDogs™ and plug-and-play functionality, Performance Series loudspeakers are quick and easy to install while still capable of delivering truly outstanding sound quality.
Bring your music home
Your home is as individual as the music you love, and so are your particular requirements. Bowers & Wilkins’ range of Integrated Solutions speakers delivers our world-famous sound quality with options to suit every type of home.
Hear music exactly as the artist intended
Our Integrated Solutions speakers are built by the same people, to the same standards, and with the same objectives, as our regular loudspeaker ranges. There’s only one difference: these speakers are nowhere to be seen.
True Sound
There’s nothing quite like experiencing the True Sound of a performance. At Bowers & Wilkins, our dedicated engineers develop and integrate the highest caliber of performance audio technology into our products. The result allows you to hear music and movies with the striking accuracy and realism of the original recording, with nothing added and nothing taken away.
Specifications
Net weight:
not provided by manufacturer
Dimensions:
Frame Diameter: Ø147mm (5.8 in)
Depth (behind surface): 100mm (4 in)
Cut-out Diameter: Ø120mm (4¾ in)
Cut-out Height with PMK: n/a
Cut-out Width with PMK: n/a
Protrusion: 5.5mm (0.22 in)
Drive units:
1x ø75mm (3in) paper cone full-range driver
Frequency range:
-6dB at 100Hz – 17kHz
Frequency response:
(+/-3dB) 112Hz - 16kHz
Sensitivity:
84dB (2.83V, 1m)
Technical features:
not provided by manufacturer
Harmonic Distortion:
not provided by manufacturer
Crossover:
not provided by manufacturer
Nominal Impedance:
8Ω (5Ω minimum)
Recommended amplifier power:
10W – 60W
Preconstruction Bracket (sold separately):
PMK C3
Back Box:
Integrated
Grille finishes:
White - square and round included
Warranty:
5 Years
