Klipsch Designer Series DS-180CDT – In Ceiling Speaker
Klipsch
$359.00
(No reviews yet)
Write a Review
Klipsch
Klipsch Designer Series DS-180CDT – In Ceiling Speaker
Klipsch Designer Series: DS-180CDT
Offering the Klipsch Signature Horn-Loaded performance at an incredible value, the DS-180CDT features a 8” Polypropylene woofer and a 1” Pivot Silk Dome tweeter mated to a round Tractrix® horn for dynamic acoustic performance. Utilizing the Sky Hook® patented Cinch by Swarm Installation System, your install time is reduced by 75%.
- 8” Pivot Polypropylene woofer
- 1” Silk Dome tweeter
- Patented Sky Hook® Tool-Free Installation System
- Bezel-Free Magnetic Grille
Highlights & Key Technologies
Horn Loaded Performance
Using the same Tractrix® horn technology and design principles of our premium architectural and box speaker lines, the all new Klipsch Designer series brings true Klipsch power and performance. With a 8” Polypropylene woofer and a pivoting 1” Silk Dome tweeter mated to a round Tractrix® horn, the DS-180CDT brings dynamic, powerful, detailed Klipsch sound to your distributed audio, home theater, or 2-channel system.
Patent Pending SKYHOOK™ Tool Free Installation
The exclusive installation system engages the dog legs automatically when the speaker is inserted into the cutout hole with a preset clamping force, eliminating the possibility of overtorquing. This fast, easy installation system reduces install time by up to 75%.
Bezel Free Magnetic Grille
A completely redesigned powercoated magnetic steel grille eliminates the bezel for seamless, pristine integration into the living space.
Details & Specifications
Using the same Tractrix® horn technology and design principles of our premium architectural and box speaker lines, the all new Klipsch Designer series brings true Klipsch power and performance. With a 8” Polypropylene woofer and a pivoting 1” Silk Dome tweeter mated to a round Tractrix® horn, the DS-180CDT brings dynamic, powerful, detailed Klipsch sound to your distributed audio, home theater, or 2-channel system.
Patent Pending SKYHOOK™ Tool Free Installation
The exclusive installation system engages the dog legs automatically when the speaker is inserted into the cutout hole with a preset clamping force, eliminating the possibility of overtorquing. This fast, easy installation system reduces install time by up to 75%.
Bezel Free Magnetic Grille
A completely redesigned powercoated magnetic steel grille eliminates the bezel for seamless, pristine integration into the living space.
Details & Specifications
Frequency Range: 73Hz - 20kHz +/- 3dB
High Frequency Driver: 1" (2.54cm) Silk Dome Tweeter mated to a round Tractrix® Horn
Low Frequency Driver: 8" (20.32cm) Polypropylene Woofer
Sensitivity: 94 dB @ 2.83V / 1m
Coverage Angle: 100°
Power Handling: 50W RMS / 200W RMS
Impedance: 8 Ohm Compatible
Enclosure Type: ABS/Infinite Baffle
Finish: Black Baffle/Frame, White Paintable Grille
Product Dimensions: 10.75” W x 10.75” H x 4.5” D (27.3cm H x 27.3cm W x 11.5cm D)
Mounting Depth: 4.45” (11.3cm)
Cutout Dimensions: 9.8” (24.9cm)
Product Weight: 7.4 lbs (3.36kg)
Included: Flat Paintable Magnetic Grille
Installation Kit: IK-800-C II (Sold Separately)
Fire Rated Enclosure: ME-800-C (Sold Separately)
Built From: 2017
Item Number: 1068516
High Frequency Driver: 1" (2.54cm) Silk Dome Tweeter mated to a round Tractrix® Horn
Low Frequency Driver: 8" (20.32cm) Polypropylene Woofer
Sensitivity: 94 dB @ 2.83V / 1m
Coverage Angle: 100°
Power Handling: 50W RMS / 200W RMS
Impedance: 8 Ohm Compatible
Enclosure Type: ABS/Infinite Baffle
Finish: Black Baffle/Frame, White Paintable Grille
Product Dimensions: 10.75” W x 10.75” H x 4.5” D (27.3cm H x 27.3cm W x 11.5cm D)
Mounting Depth: 4.45” (11.3cm)
Cutout Dimensions: 9.8” (24.9cm)
Product Weight: 7.4 lbs (3.36kg)
Included: Flat Paintable Magnetic Grille
Installation Kit: IK-800-C II (Sold Separately)
Fire Rated Enclosure: ME-800-C (Sold Separately)
Built From: 2017
Item Number: 1068516
UPC: 743878042344
