Klipsch KDA-500 – 4 Channel 125W Distribution Amplifier

High Performance Power Platform
The Klipsch KDA Series DSP Amplifiers offer legendary Klipsch power and performance in a sleek, high-tech, 1 rack unit solution. The KDA-500 offers 500W of class G/H power, for clean, dynamic power in any type of install.

70V / 100V / Low Impedance Compatibility
From small residential systems to massive commercial installs, the Klipsch KDA-500 is designed for maximum install flexibility – offering low impedance and 70V/100V compatibility for distributed line applications. These impedance settings are fully independant from channel to channel – so an installer can run one channel low impedance with another channel 70V/100V for full customization and optimization of their system.

Flexible I/O
The KDA-500 boasts fully matrixed 4x4 I/O with fully balanced Phoenix connector inputs and Phoenix speaker outputs capable of connecting up to 12 gauge wire. For non-balanced connections, RCA inputs and outputs (throughs) are also built-in, making the KDA-500 one of the most flexible power solutions on the market today.

State of the Art DSP
The myriad of I/O, impedance, and acoustic settings are fully matrixed and customizable through the web-based DSP menu - simply plug in a laptop computer to the RJ-45 port on the back panel of the amplifier, enter the assigned IP address into your favorite web browser to pull up the easy-to-use, streamlined menu page. In addition to password protected channel assignments, gain settings, EQ, and limiting, the DSP provides presets for almost every Klipsch speaker on the market – optimizing acoustic performance and power handling for these products with a single click. Accessing the DSP wirelessly with a tablet, smartphone, or computer is also quick and easy when
the KDA amplifier is plugged into the network’s wireless router.

Details & Specifications

Amplifier Type: High Efficiency Class G/H
Amplifier Power: 500W Total System Power 4 x 125W Per Channel
Inputs: Balanced: 4 x Phoenix Line Level (up to 12 AWG wire) Unbalanced: 4 x RCA Line Level
Outputs: 4 x Phoenix Speaker Level (up to 12 AWG wire) 4 x RCA Line Level (Throughs)
Input Sensitivity: 750mV Balanced, 0dBU
Input Impedance: Balanced 40k
THD: <1% @ Rated Output
Signal-To-Noise: -100dB Below Rated Output
Enclosure Type: Front Face: ABS Plastic Case: Machine Formed Steel
Rack Unit: 1RU
Product Dimensions: 1.73” x 19.02” x 14.29” (44mm x 483mm x 363mm)
Product Weight: 15 lbs (6.82 kg)
Mounting Options: Removable 1RU Rack Ears, Removable Rubber Feet
Built From: 2016
Item Number: 1063257
UPC: 743878030242
