Panamorph CDR-G2 + XM3 – Anamorphic Lens System
Panamorph
$6,995.00
(No reviews yet)
Write a Review
Panamorph
Panamorph CDR-G2 + XM3 – Anamorphic Lens System
Panamorph CDRG2 + XM3 – Anamorphic Projector Lens System
Leveraging our award winning CDR optics, our G2 (second generation) lens system is now packaged with the XM3 universal attachment kit for ceiling or shelf-mounting compatible projectors. Note that like the previous CDR lenses, these models do not change the width of the image – only the height – as they convert the full native resolution of the projector to the 2.4:1 cinema format with millions of more pixels for higher brightness and detail.
Why Do I Need This?
Panamorph's 8K rated anamorphic conversion lenses work in conjunction with the internal anamorphic modes of modern home theater projectors to provide up to a 30% increase in brightness levels on screen by recapturing millions of what would otherwise be unused black bar pixels, inserting them on to the projected image, all while maintaining video fidelity of the original source. The bottom line is this: running without an anamorphic lens results in NOT using the full pixel capability of your projector.
- Compatible Sony Projectors: XW series models
- Compatible EPSON Projectors: QB1000, long throw LS series models (LS12000, LS11000, LS9000)
- Compatible JVC Projectors: n/a
- Compatible BenQ Projectors: n/a
- Recommended throw distance between 12 and 30 feet
- Lenses support projectors up to 10,000 lumens
- CDR-G2 lenses optimized for use of 16:9 display panels or the 16:9 portion of 17:9 display panels in most projectors having anamorphic modes.
- CDR G2 applies a higher magnification, so an additional amount of barrel distortion should be expected (although Epson has the “point correction” feature to mitigate this.
- Accepts a beam up to 58mm W x 44mm H
- 2 million more pixels on your 2.4:1 format screen for stunning detail and 30% higher brightness when showing 2.4:1 movie and streaming content.
- Does not change the projector throw ratio. Greater distortion with the CDRG2 can be corrected to a rectangular image using Epson’s “Point Correction”.
- Sealed, precision, proprietary all-glass optical system.
- Instant aspect ratio changes. No need for lens adjustments in shift/zoom/focus.
- Optimized for vertical position of the projector in typical home theaters from -6″ to +16″ from screen top and +/- 4” from screen horizontal center (greater with higher throw ratios).
- Additional projector mode fills the 2.4:1 screen with stretched 16:9 content.
- Weight: Lens and bracket: 3 pounds (1.4Kg), XM3 plate: 5 pounds (2.3Kg).
- Dimensions: Lens only: 3.7” (94mm) D X 4.3” (109mm) H X 5.4” (136mm) W. Allow 4.2” (105mm) in front of the projector lens for mounting and adjustments before obstructions in front of the anamorphic lens
