Perlisten R7t – Floorstanding Tower Speaker

Perlisten Audio R7t – Floorstanding Tower Speaker

Designed as a standalone 2-channel high fidelity speaker with the versatility to be used as part of multi-channel systems. Sharing trickle-down technology from the flagship S-Series, the DPC-Array — here based on three 26mm silk domes — guarantees excellent directivity control and timbre matching with all R-Series speakers. The silk diaphragms were developed ground up, chosen specifically for their smooth, effortless representation of midrange and treble. The 165mm woofers are made from Perlisten's proprietary HPF pulp, two years in development, bringing new technology to one of the oldest materials used in loudspeaker design. The R7t can be aligned as bass reflex or acoustic suspension depending on specific tastes.

• DPC-Array: (3) 26mm silk dome, directivity pattern control
• (4) 165mm HPF (Hybrid Pulp Formulation) diaphragm woofers
• 4-way bass reflex / acoustic suspension enclosure
• 4Ω nominal / 3.1Ω minimum impedance
• Frequency Response (-10dB): Bass reflex: 27–32kHz; Acoustic suspension: 38–32kHz
• 90.0dB / 2.83v / 1.0m Sensitivity
• THX Dominus and THX Ultra Certified
• Weight: 48.0 kg (105.6 lbs.)
• Made in China
• 5 Year Warranty

Highlights & Key Technologies

DPC-Array & Directivity Pattern Control
At the heart of the R7t's mid and treble performance is the DPC-Array — a directivity pattern control system based on three 26mm silk dome drivers. Sharing trickle-down technology from the flagship S-Series, this array guarantees excellent directivity control with beam forming down to 500Hz, and ensures timbre matching with all R-Series speakers. The silk diaphragms were developed ground up, chosen specifically for their smooth, effortless representation of midrange and treble. The DPC-Array patent is USA patent pending.

HPF Woofers
The R7t employs four 165mm woofers made from Perlisten's proprietary HPF (Hybrid Pulp Formulation) — a material two years in development combining long fiber hardwood, bamboo, and wool. This brings new technology to one of the oldest materials used in loudspeaker design, delivering long-excursion performance for extremely low distortion and rich, dynamic bass.

Enclosure Alignment
The R7t can be aligned as either bass reflex or acoustic suspension depending on specific tastes. In bass reflex alignment, frequency response extends to 27Hz (-10dB) with typical in-room bass extension reaching 19Hz. In acoustic suspension alignment, frequency response extends to 38Hz (-10dB) with typical in-room bass extension of 30Hz.

THX Dominus & THX Ultra Certification
The R7t is certified THX Dominus and THX Ultra.

Details & Specifications

MODEL INFORMATION
Model: R7t
Certification: THX Dominus, THX Ultra
Available Finishes: Piano black / High Gloss Black

DRIVER COMPLEMENT
DPC-Array: 26mm(3) Silk dome
Woofers: 165mm(4) HPF diaphragms

ENCLOSURE
Enclosure Alignment: 4-way bass reflex / acoustic suspension

PERFORMANCE
Sensitivity: 90.0dB / 2.83v / 1.0m
Impedance: 4Ω nominal / 3.1Ω min
Response Linearity: 80–20kHz ±1.5dB window
Frequency Response (-10dB):
  • Bass reflex: 27–32kHz
  • Acoustic suspension: 38–32kHz
Typical In Room bass extension:
  • Bass reflex: 19Hz
  • Acoustic suspension: 30Hz
Recommended Amplifier Power: 100–400W RMS
SPL capability @1m (100–20kHz): 116.0dB peak; 116.0dB peak <3% - 2nd, 3rd Harmonics

PHYSICAL SPECIFICATIONS
Dimensions (HxWxD): 1268 x 230 x 350mm / 49.9" x 9-1/16" x 13-3/4"
Height with grill: 49-15/16" (1267.9mm)
Width with outriggers: 16-9/16" (420.0mm)
Depth without grill: 13-1/4" (336.0mm)
Depth with grill: 13-13/16" (350.5mm)
Terminal protrusion: 1-1/2" (38.0mm)
Outrigger base depth: 14" (355.0mm)
Weight: 48.0 kg (105.6 lbs.)

WARRANTY
5 Year Warranty

ORIGIN
Made in China
