RBH Signature 661-SF – Stand Mount Bookshelf Speaker

RBH Sound 661-SF – LCR Stand Mount Bookshelf Speaker

The reality of a perfectly timbre-matched home theater is possible when using the 661-SF. This speaker can be used as left and right main channels for music and home theater systems, or can also be used as a center channel or surround channel. The versatile 661-SF utilizes dual 6½-inch aluminum cone woofers and a 1-inch fabric dome tweeter to deliver clear dialog and vibrant on-screen sound effects with superb clarity.

• (1) 1" (25mm) fabric dome tweeter
• (2) 6½" cast aluminum basket, aluminum cone woofers, silver or black-anodized
• Dual rear ported cabinet
• 6 ohm impedance
• 2700 Hz crossover, 24 dB/Octave
• 50–20,000 Hz (±3dB) Frequency Response
• 90 dB Sensitivity
• Designed, Engineered, Tested and Assembled in USA from American and Imported Parts
• 10 Year Limited Warranty

Highlights & Key Technologies

MTM Driver Configuration
The 661-SF features a mid-tweeter-mid (MTM) configuration, combining dual 6½-inch cast aluminum basket aluminum cone woofers — available in silver or black-anodized — with a centrally positioned 1-inch fabric dome tweeter with tweeter protection. The two-way crossover is set at 2700 Hz with a 24 dB/Octave slope. This configuration combines the power of multiple drivers for greater dynamic response and directivity, making the 661-SF equally suited as left and right main channels, a center channel, or surround channels in home theater applications.

Vented HDF Cabinet
The 661-SF cabinet is constructed from ¾-inch High Density Fiberboard (HDF) with heavy internal bracing, individually hand assembled and tested in the USA, and is available in satin black or white. The cabinet features dual rear ports. A magnetically attached black or white high quality fabric grille with a ½" MDF frame is included.

SF Series Compatibility
The 661-SF provides timbre-matched options for multi-channel sound across all freestanding, bookshelf, on-wall, and in-wall products in the SF, SV, and SI Series.

Details & Specifications

MODEL INFORMATION
Model: 661-SF
Series: Signature Series | Freestanding Speaker
System Type: Vented / LCR 2-way Speaker

DRIVE UNITS
(2) 6-1/2" (165mm) cast aluminum basket, aluminum cone (silver or black-anodized)
(1) 1" (25mm) Fabric Dome Tweeter

PERFORMANCE
Frequency Response: 50–20k Hz (±3dB)
Sensitivity: 90 dB (2.83V @ 1 Meter)
Recommended Power: 75–200 Watts
Impedance: 6 Ohms
Tweeter Protection: Yes

CROSSOVER
Crossover Frequency: 2700 Hz
Crossover Slope: 24 dB/Octave

CABINET
Cabinet Material: High Density Fiberboard (HDF), ¾" construction, heavy internal bracing
Cabinet Color: Satin Black or White
Grille: White or Black high quality fabric, ½" MDF frame, magnetically attached

PHYSICAL SPECIFICATIONS
Finished Dimensions: 7-3/4" x 22-3/8" x 12-3/8" (197 x 569 x 315mm)
Weight: 21 lbs (9.53 kg)

WARRANTY
*10 Year Limited

ORIGIN
Designed, Engineered, Tested and Assembled in USA from American and Imported Parts
