Denon AVR-S570BT – 5.2 Ch. 70W 8K AV Receiver

AVR-S570BT 5.2 Ch. 70W 8K AV Receiver

Bring movies to life in smaller spaces with amazing 8K picture quality and true surround sound. Enjoy all your favorite entertainment with 5.2 channel surround sound and wireless music streaming via Bluetooth. The AVR-S570BT features Dolby Vision™, HDR10+, and offers four HDMI inputs and one output with the latest HDMI specification. The 5.2 channel design delivers a full surround sound experience. Stream your favorite music tracks wirelessly via Bluetooth. The award-winning Denon Setup Assistant makes the Denon AVR-S570BT as easy to set up as it is to enjoy.

Highlights

Powerful discrete 5-channel amplifier
With up to 70W (at 8 ohms, 20-20kHz, THD 0.08%, 2ch driven), AVR-S570BT has enough power to drive any speaker for quality sound.

Advanced 8K HDMI connection
K/60Hz, 4K/120Hz, HLG, HDR, Dolby Vision, HDR10+ pass-through, and 8K upscaling are supported on all four HDMI inputs and one output, for maximum bandwidth up to 40Gbps.

Enhanced gaming experiences
Supports Variable Refresh Rate (VRR), Quick Frame Transport (QFT) and Auto Low Latency Mode (ALLM) for smooth, lag-free gaming experience.

Simple, intuitive setup
Setup is simple. Our award-winning guided setup assistant provides clear, step-by-step instructions to get you started.

Easy wireless music streaming
Your favorite tracks at your fingertips. Stream music from your smart devices via Bluetooth.

Denon Quick Selects
Press one of the four Quick Select buttons to easily store and retrieve your favorite audio settings, such as input source, volume level, or sound mode.

Remote control app
The Denon 500 series AVR Remote app allows you to turn the receiver on and off, select an input source, adjust volume level, and browse music from your phone or a USB drive.

Over a century of innovation
Founded in 1910, Denon enhances the moments that matter through the relentless pursuit of quality, innovation, and audio performance.

Key Technologies

Dolby Audio
High-fidelity lossless Dolby TrueHD and Dolby Digital, Dolby Digital Plus signal decoder, and Dolby Pro Logic II upmixer for 2-channel audio signals to create a full 5.1 surround sound experience.

DTS Surround Technology
High-fidelity lossless DTS-HD and DTS Surround, DTS 96/24 signal decoding, along with DTS Neo 6 upmixer for 2-channel audio signals to create a full 5.1 surround sound experience.

HDMI Connectivity with ARC/eARC
Supports the latest technology on all HDMI inputs and the output. ARC (Audio Return Channel) or eARC (Enhanced Audio Return Channel) makes playing TV audio through your AV receiver simple with just a single HDMI connection. eARC provides HD and 3D audio transmission such as Dolby TrueHD, DTS HD Master Audio, and Dolby Atmos while ARC is limited to conventional 5.1ch audio formats or PCM.

8K/HDCP 2.3
Enjoy pristine picture quality on your 8K TV or projector. 8K/60Hz pass-through and 8K upscaling on 1080p or 4K content is supported on all four HDMI inputs and one output. Supports HDCP 2.3, the latest copy protection standard, for peace of mind when streaming copy protected content.

HDR 10+
Supports HDR (High Dynamic Range), HLG (Hybrid Log Gamma), as well as Dynamic HDR and HDR10+ pass-through. HLG offers HDR technology over broadcast content. Both Dynamic HDR and HDR10+ use dynamic metadata to optimize shadows and highlights as screens change.

Dolby Vision
Dolby Vision is a stunning HDR imaging technology that brings extraordinary color, contrast, and brightness to the screen.
Compatible with Dolby Vision so you can enjoy Dolby Vision content from a compatible source device and TV.

Next-generation gaming
4K/120Hz pass-through as well as Variable Refresh Rate (VRR), Quick Frame Transport (QFT) and Auto Low Latency Mode (ALLM) are supported on all four HDMI inputs and one outputs for a lag-free, smoother gaming experience when connected with the compatible gaming devices.

ARC / eARC
ARC (Audio Retrun Channel) or eARC (Enhanced Audio Return Channel) makes playing TV audio through your AV receiver simple, with just a single HDMI connection. Also supports HDMI CEC so you can use your TV's remote to control TV power, AV receiver power, and the AV receiver volume level.

Wireless music streaming via Bluetooth
Enjoy listening to your favorite audio content wirelessly from your smart devices.

High-resolution audio via USB input
Discover the incredible fidelity of high-resolution audio tracks and enjoy music as the artist intended. A front USB port supports up to 24bit/192kHz hires audio playback from a USB drive. Supported audio formats are MP3, WMA, WAV, MPEG- 4/AAC, FLAC, and ALAC.

Quick Select
Press one of the four Quick Select buttons on the front panel to easily store and retrieve your favorite audio settings, such as an input source, volume level, or sound mode. You can also access Quick Select buttons on the Denon 500 series remote app downloaded on your phone.

Denon 500 Series Remote App
This iOS or Android control app allows you to turn the receiver on and off, select an input source, adjust volume level, and browse music from your phone or in a USB drive when connected to the receiver.

Dual subwoofer outputs
Immerse yourself in evenly distributed, accurate bass. Two subwoofer outputs smooth out low frequencies and provide better dispersion. No audible peaks or dips—just powerful, room-filling bass.

Denon Setup Asisstant on TV
The award-winning Denon guided setup assistant provides simple, clear instructions to get started. Just connect your AV receiver to your TV and follow the instructions on the TV screen to connect you speakers, perform speaker measurements, and connect source devices.

Auto setup and room EQ
As part of setup, follow the instructions on your TV to completer speaker setup and measurement using the included microphone. The receiver uses the measurements to optimize sound for the room, bringing the best out of your system. Just sit back and enjoy great sound.

Details & Specifications

Multichannel Surround
DTS HD Master, DTS:X, DTS:X Pro: Yes, No, No
DTS Neo:X, DTS Neural:X: No, No
Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music: Yes, No, No, No
Dolby ProLogic Ilz, Dolby Surround: No, No
Multichannel Stereo: Yes
Max. Number of Processing (Pre-Amp) Channels: 5.1

Sound Enhancements
Discrete Power Amplifier: Yes
Pure Direct: Yes
Audyssey Dynamic EQ, Dynamic Volume: No, No
Compressed Audio Restorer: Yes

Network
Alexa / Google Voice Assistant / Apple HomePod: No, No, No
Lossy Formats: MP3, WMA, AAC: No, No, No
Lossless Formats: FLAC, ALAC, WAV: No, No, No
Lossless Formats: FLAC HD, WAV, ALAC (all 192kHz/24 bit): No, No, No
Compatible with Remote APP for Smart Phones: Denon 500 Series Remote
Bluetooth: Yes

HDMI
HDMI Inputs: Back, Front: 4, No
HDCP2.3 support: Yes
HDMI Outputs: Main, Zone: 1 / No
HDMI 2.1: 8K/60Hz AB, 4K/120Hz AB: Yes, Yes
HDR, HLG, Dolby Vision, HDR10+, Dynamic HDR: Yes , Yes, Yes, Yes, Yes
Variable Refresh Rate, Quick Frame Transport, Quick Media Switching: Yes, Yes, No
3D Signal Pass-through: Yes
8K Signal Pass-Through, Scaling, GUI Overlay: Yes, Yes, Yes
Audio Return Channel (ARC), Enhanced ARC: Yes, Yes

Multi-room CI
Zone Audio Source: HDMI; Optical, Coax, Network, USB; Analog: No, No, No, No
Zone Audio Output: Speaker, Pre-Out: No, No
IP Control, RS232 Control, Web Control, App Control: No, No, No, No
Remote In / Out: No, No

Others
Auto Speaker Setup by Microphone: yes
Front Display: 1-Line FLD
GUI Languages: 3
Setup Assistent: Yes
Quick Select Plus, Quick Select: Yes, No
Variable Crossover: Yes
ECO Mode: Yes
Auto Power Off: Yes
Sleep Timer: Yes

Inputs Outputs
HDMI In, Out: 4, 1
Multi-Room Video Out: Video, HDMI: No, No
Analog In, Out: 2, No
Digital In: Optical, Coaxial: 2, 1
Multi-Room Out: Analog, Digital: No, No
Multichannel Pre-out: Yes (0.2)
Subwoofer Out: 2
Speaker Terminal: Gold-Plated Screw, Regular Screw: No, No
Number of Speaker Terminals: 5
Front Inputs: Audio, Composite, Digital (Opt), HDMI, USB: No, No, No, No, Yes
USB Audio, Made for iPod, Made for iPhone: Yes, No, No
AM/FM Tuner: Yes

Specifications
Number of Power Amps: 5
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive): 70W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive): 90W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive): 140W

General
System Remote Control: RC-1254
Pre-Programmed, Learnable, LCD Display: No, No, No
Power Consumption in W: 310
Power Consumption No-Sound (ECO On / Off) in W: 26W/35W
Standby Consumption in W: 0.1
CEC Standby Consumption in W: 0.5
Dimensions: Antenna: Horizontal: (W x D x H) in Inches: 17.1 × 13 × 6
Dimensions: Antenna: Vertical: (W x D x H) in Inches: n/a
Dimensions: W/O Antenna: (W x D x H) in Inches: n/a
Weight in LBS: 16.8
