Denon AVR-S770H – 7.2 Ch. 75W 8K AV Receiver with HEOS®

AVR-S770H 7.2 Ch. 75W 8K AV Receiver with HEOS® Built-in

Enjoy incredible 8K video and 3D audio from the AVR-S770H. Fill small to mid-size rooms with sound from a 7.2 or 5.2.2 surround sound set up with Dolby Atmos and DTS:X. And with HEOS® Built-in, you can stream and share music to any HEOS-enabled speaker throughout your home.

Highlights

High performance discrete 7-channel amplifier
Discrete high-current amplifiers on all channels deliver up to 75W per channel (at 8 ohms, 20-20 kHz, THD 0.08%)— enough power to drive most speakers in a mid-size room.

3D audio experience
Elevate your music and movies with Dolby Atmos® and DTS:X® plus Dolby Surround and DTS Neural:X upmixer to optimize legacy content.

Advanced 8K home theater
8K video is supported on three of six HDMI inputs and one output. Enjoy easy video compatibility and great picture quality with HLG, HDR, Dolby Vision, HDR10+, and Dynamic HDR pass-through.

HEOS® Built-in technology
Stream music wirelessly to compatible HEOS-enabled components from a variety of streaming services. Add Denon Home speakers to additional rooms and control it all with the HEOS app.

Built-in Wi-Fi and Bluetooth
Provides both Wi-Fi and Bluetooth connectivity for your wireless network or direct music streaming from your smart devices. Use AirPlay to stream Apple Music.

Simple setup and Audyssey room correction technology
Our award-winning guided setup assistant provides clear, step-by-step instructions to get you started. Includes Audyssey MultEQ software for accurate calibration that optimizes the listening experience in your room.

Over a century of innovation
Founded in 1910, Denon enhances the moments that matter through the relentless pursuit of quality, innovation, and audio performance.

Key Technologies

Dolby Atmos®
Feel every dimension in Dolby Atmos. Upgrade your home theater with a 5.1.2 speaker setup to unleash a fully immersive 3D audio experience from Dolby Atmos content. Dolby Surround upmixer engages all speakers to create 3D audio sensation from legacy content. Dolby Atmos Height Virtualization Technology creates the sensation of overhead sound even without a 5.1.2 system. You can also enjoy Dolby Atmos music tracks available from Apple Music, Amazon HD, and TIDAL and a compatible streaming device.

DTS:X
DTS:X immersive audio content places sound where it would naturally occur in space, creating lifelike, multi- dimensional
audio. DTS Neural:X upmixer offers improved immersion and heightened realism for legacy content. DTS Virtual:X provides immersive audio without height channels, creating virtual height effects in a 7.1, 5.1, or 2.1 speaker setup.

HDMI Connectivity with ARC/eARC
Supports the latest technology on all HDMI inputs and output. ARC (Audio Return Channel) or eARC (Enhanced Audio Return Channel) makes playing TV audio through your AV receiver simple, with just a single HDMI connection. eARC provides HD and 3D audio transmission such as Dolby TrueHD, DTS HD Master Audio, and Dolby Atmos while ARC is
limited to conventional 5.1ch audio formats or PCM.

8K/HDCP 2.3
Enjoy pristine 8K picture quality on your 8K TV or projector. Supports both 8K pass-through and 8K upscaling of 4K content. Supports HDCP 2.3, the latest copy protection standard, for peace of mind when streaming copy-protected
content.

Brilliant color from HDR 10+
Supports HDR (High Dynamic Range), HLG (Hybrid Log Gamma), as well as Dynamic HDR and HDR10+ pass-through.
HLG offers HDR technology over broadcast content. Both Dynamic HDR and HDR10+ use dynamic metadata to optimize
shadows and highlights as screens change.

Dolby Vision
Dolby Vision is a stunning HDR imaging technology that brings extraordinary color, contrast, and brightness to the screen.
Compatible with Dolby Vision so you can enjoy Dolby Vision content from a compatible source device and TV.

Next-generation gaming
Supports Variable Refresh Rate (VRR), Quick Frame Transport (QFT), and Auto Low Latency Mode (ALLM) for smooth,
lag-free gaming experience when connected with the compatible gaming devices.

HEOS® Built-in
With HEOS Built-in, your AV receiver can stream music wirelessly across compatible HEOS components from a variety
of free and premium streaming services. Consumers can also enjoy their favorite music in any room of the home wirelessly. Play the same song in every room or select a different song for each connected room via a variety of streaming sources. Add Denon Home speakers to more rooms and control it all with the HEOS app.

Apple Siri Voice Control
With Siri compatibility, users can play music, adjust volume, and switch inputs using voice control. AirPlay 2 features in compatible devices can also be controlled with your voice via Siri.

Works With Amazon Alexa
Control your AV receiver hands- free with Amazon Alexa and your voice. Adjust the volume, skip to the next track, switch
inputs for your different media players, and more—“Just Ask.” Download the free HEOS Home Entertainment Skill to enable Amazon Alexa voice commands. Requires Alexa app and Amazon Echo, Dot, or equivalent.

High-resolution audio via USB input
Enjoy superb audio fidelity with your favorite high- resolution audio tracks. The supported formats are ALAC, FLAC, and
WAV at up to 192kHz/24bit. It is also compatible with 2.8/5.6-MHz DSD files. Play HD audio tracks from a USB drive or other connected drives over network or from Amazon Music HD with subscription. Conventional MP3 and WMA files are also
supported.

Bluetooth audio transmitter
Pair your favorite Bluetooth headphones with your AV receiver to continue listening to your favorite music, movies, or TV
programs at night. You can also play audio from both speakers and Bluetooth headphones simultaneously. If you have a family member or a friend who is hearing impaired, we recommend this setup. You can connect one pair of headphones at a time.

Multi-source, multi-room
By connecting a pair of speakers in a second room to the AV receiver, it’s possible to enjoy 5.1-channel surround sound in
the main room and a separate source or music stream in the second room, such as den or patio. You can also play the same audio in both so that everyone in your home can enjoy and cheer your favorite team on Sunday evening or listen to the same song in both rooms. The AV receiver supports 2-source, 2-zone audio.

Denon Setup Assistant
Award-winning guide Denon Setup Assistant supplies simple, clear instructions to get started. Just connect your AV receiver to your TV and follow the instructions on the TV screen to connect your speakers, perform speaker measurements, and connect source devices. For additional convenience, the AV receiver renames HDMI inputs automatically when connected or you can rename manually at your convenience.

Audyssey suite of room correction technology
Denon AV receivers use the Audyssey suite of EQ software for simple, accurate setup and calibration. With the supplied
Audyssey measuring microphone, Audyssey measures all the speakers in your home theater, and tunes the AV receiver
to provide the smoothest, most optimal overall listening experience for your room. This AV receiver supports Audyssey
MultEQ room-correction technology. The other supported Audyssey features are Dynamic EQ and Dynamic Volume.

Audyssey MultEQ XT
You can go even further with the Audyssey MultEQ Editor app, going “under the hood” to view and adjust settings for detailed tuning—allowing you to customize the sound more precisely to the specific problems in your room and tailor the sound to your personal preferences. With this comprehensive app, you can harness the power of Audyssey MultEQ to take total control of the way your home cinema sounds. The app is available for purchase in iOS and Google Play stores.

Denon AVR Remote app
This iOS or Android control app allows you to control your AV receiver, such as changing inputs, sound modes, volume, store and retrieve Quick Selects, show AVR status, input and output signal information, change optional settings and so on. Once HEOS music is selected, the AVR remote app automatically switches to the HEOS app for seamless operation between two apps.

Google Home Assistant
Start music in the HEOS app, then ask your Google Assistant to control volume, play, pause, skip tracks, mute, and unmute.

Josh.ai
Josh.ai offers flexible voice control for nearly any aspect of your day-to-day experience and entertainment environment.
Use voice commands to control the thermostat, lights, home appliances, speakers, AV receiver, and more. Josh.ai is installed by custom integrators and accessed through an app on your phone or tablet. Works with iOS and Android devices.

Spotify Connect
Stream your music directly from your Spotify account for high-quality music in your TV room.

Roon Tested
Get more out of your digital music library with searchable, surfable information about your favorite artists and songs. Find lyrics, concert dates, photos, bios, reviews and more.

Apple Airplay 2
Stream audio or video from your favorite streaming services using your smart device. Hear audio perfectly synced to your speakers from AirPlay 2 sources. AirPlay 2 also supports multi-room audio.

Details & Specifications

Multichannel Surround
DTS HD Master / DTS:X / DTS:X Pro: Yes / Yes / No
DTS Neo:6 / DTS Neural:X: No / Yes
DTS Virtual:X: Yes
Dolby TrueHD / Dolby Atmos / Dolby Atmos Height Virtualization / Dolby Atmos Music: Yes / Yes / Yes / Yes
Dolby ProLogic Il / Dolby Surround: No / Yes
Multichannel Stereo: Yes
Dialog Enhancer: Yes
Max. number of processing (preamp) channels: 7.1

Sound Enhancements
Discrete Power Amplifier: 7
Audyssey: MultEQ
Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
Compressed Audio Restorer: Yes

Network
Media Server: Yes
HEOS Wireless Multi-Room Technology: Yes
Bluetooth Re-Transmit for Bluetooth Headphones: Yes (with volume control)
Alexa / Google Voice Assistant / Apple HomePod: Yes / Yes / Yes
Lossy Formats: MP3 / WMA / AAC: Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV: Yes / Yes / Yes
Lossless Formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24: Yes / Yes / Yes
DSD Audio Streaming: Yes (2.8/5.6MHz)
FLAC HD 192/24: Yes
WAV 192/24: Yes
ALAC 192/24: Yes
Gapless playback: Yes (FLAC, WAV, ALAC ,DSD)
AirPlay Audio Streaming: Yes (AirPlay2)
Internet Radio: Yes (TuneIn)
Spotify: Yes (connect)
Pandora: Yes
SiriusXM: Yes
Other Streaming Services: Amazon Music HD / Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / Soundcloud / Mood Mix
Roon Tested: Yes
HEOS App Control: Yes
Compatible with Remote APP for Smart Phones: Denon AVR Remote
Compatible with Remote APP for Tablets: Android / iOS / Amazon Kindle
Ethernet Ports: Yes
Wi-Fi: Yes
Bluetooth: Yes

HDMI
HDMI Inputs: Back/Front: 6 (3x 8K) / Yes
HDMI Outputs: Main/Zone: 1 / No
HDMI max Resolution (8k / 4k): 8k/60 - 4k/120
HDMI to HDMI Scaling: up to 8K 60/50
HDMI: 8K / 4K / CEC / eARC: Yes / Yes / Yes / Yes
HDMI: Dolby Vision / HDR 10+ / Dynamic HDR /HLG: Yes / Yes / Yes / Yes
HDMI: ALLM / QMS / QFT / VRR: Yes / No / Yes / Yes
HDMI Pass-Though in Standby Mode: Yes

Multi-room CI
HEOS Multiroom integrated: Yes
TV Sound grouping: Yes
Multiroom zones: 2
Main room multichannel audio - Zone stereo downmix: Yes
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: Yes (2ch) / Yes (2ch) / Yes / Yes
Zone Audio Output: Speaker / Pre-Out: Yes / No
Webbrowser Setup: Yes
IP Control / RS232 Control / Web Control / App Control: Yes / No / Yes / Yes

Others
Voice Control - Works with Amazon Alexa: Yes
Voice Control - Google Assistant / Apple Siri: Yes
Auto speaker setup by microphone: Audyssey MultEQ
Front Display: 1 line FLD
Graphic User Interface - GUI: High Definition 1080p
GUI languages: 3
Setup Assistant: Yes
Quick Select Plus / Quick Select: Yes / No
Firmware Update by Network / USB: Yes / Yes
Variable Crossover: Yes
Optimized Bass Redirection: Yes
HDMI Diagnostic Mode: Yes
ECO Mode: Yes
Auto Power off: Yes
Sleep Timer: Yes

Inputs Outputs
HDMI In/Out: 6 / 1
Analog In/Out: 2 / No
Phono (MM) In: Yes
Digital in: Optical/Coaxial: 2 / 1
Multichannel Pre-Out: Yes (0.2)
Subwoofer Out: 2
Speaker Terminal: Gold-Plated Screw / Regular Screw: No / Yes
Number of Speaker Terminals: 7
Multi-Room Speaker Terminal: assignable
USB Audio Input Front: Yes
USB Power 5V/1.5A Rear: Yes

Specifications
Number of Power Amps: 7
Power Output (8 ohm, 20 Hz–20 kHz, 0.08% 2ch Drive): 75 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive): 110 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive): 165 W

General
Available colors: Black / Premium Silver: Yes / No
System Remote Control: RC-1257
Power Consumption in W: 400
Power Consumption No-Sound (ECO on / off) in W: 29 W / 39 W
Standby Consumption in W: 0.1
CEC Standby Consumption in W: 0.5
Network Standby Consumption in W: Less than 2.0
Dimensions: Antenna: Horizontal: (W x D x H) in Inches: 17.1× 13.3 × 6.0
Dimensions: Antenna: Vertical: (W x D x H) in Inches: n/a
Dimensions: W/O Antenna: (W x D x H) in Inches: n/a
Weight in LBS: 19.0
