Built upon decades of rich heritage, designed with timeless style, and engineered for utmost performance, Marantz CINEMA Series are the foundation of the world's most demanding home theaters.

Exquisite Design

A modern expression of timeless design principles, AMP 10 features the iconic Marantz porthole level meter, premium materials, and subtle sidelights that illuminate the front panel.

Ultimate Performance

We developed custom Class D amplifiers and refined our own HDAM-SA2 technology to create the most incredible theatrical experience possible in your home.

Sound Master Tuned

The Marantz Sound Master meticulously tuned AMP 10 for amazing performance with our proprietary HDAM amplification circuitry to create the Most Musical Sound in your home.

Technology Leader

AMP 10 is engineered using best-in class technologies to enable extraordinary power output; high channel count; and the dynamic, rich, warm sound for which Marantz is highly renowned.

Details & Specifications

Amplifier Class: D
IP Control / RS232 Control / Web Control / App Control: No / Yes / No / No
IR Flasher In: Yes
Marantz Remote Bus: Yes
DC Trigger Input/ Output: 1 / 1
Front Display: Level Meter
Firmware Update by Network / USB / RS232C: No / No / No
Auto Power off: Yes
Main Amplifier in: Balanced & Unbalanced: 16ch (Exclusive use by a selector switch.)
Speaker Terminal: SPKT-1+
Number of Speaker Terminals: 16
Bi-Amp Drive /BTL Drive: Yes / Yes
Level Meter: Yes
Chasiss: Copper Plated
Number of poweramps: 16
Power Output (8 ohm, 1 kHz, 0.05% 2ch Drive) Normal / BTL: 200W / 400W
Power Output (4 ohm, 1 kHz, 0.7% 2ch Drive) Normal: 400W
Power Output (8 ohm, 1 kHz, 0.7% 5ch Drive) Normal: 200W
70% Guarantee (Normal/Bi-Amp/BTL): Yes
100% Guarantee (Normal/Bi-Amp): Yes
Metal Front Panel: Yes
Pre-Programmed / Learnable / LCD Display: No / No / No
Power Consumption in W: 500
Power Consumption No-Sound in W: 140W
Standby Consumption in W: 0.2
Dimensions: 17.4 x 19.2 x 7.4 in.
Weight: 43.7 lb.
What's in the box: Main unit, quick start guide, AC cord, Amp control cable, Remote control cable, SP terminal wrench
UPC code: 747192137519
