Built upon decades of rich heritage, designed with timeless style, and engineered for utmost performance, Marantz CINEMA Series are the foundation of the world's most demanding home theaters.

Exquisite Design

A modern expression of timeless design principles, AV10 features the iconic Marantz porthole, premium materials, and subtle sidelights that illuminate the front panel.

Peerless Performance

Immersive spaciousness, warm and rich tone, extraordinary detail and lifelike dynamics are legendary hallmarks of Marantz sound.

Sound Master Tuned

The Marantz Sound Master meticulously tuned AV 10 for amazing performance with our proprietary HDAM amplification circuitry to create the Most Musical Sound in your home.

Technology Leader

AV 10 comes packed with the latest immersive audio formats, 8K video, room optimization, streaming, and more technology to simplify and elevate your enjoyment.

For the Soundtrack of Your Life

HEOS® Built-in has a search feature that lets you find and stream from the world’s leading music platforms, including TIDAL, Pandora, and Amazon Music HD.

Details & Specifications

Multichannel Surround
DTS HD Master / DTS:X / DTS:X Pro: Yes / Yes / Yes
DTS Neo:X / DTS Neural:X: No / Yes (15ch)
DTS Virtual:X: Yes
IMAX Enhanced: Yes
Dolby TrueHD / Dolby Atmos / Dolby Atmos Height Virtualization / Dolby Atmos Music: Yes / Yes / Yes / Yes
Dolby ProLogic Ilz / Dolby Surround: No / Yes
Auro 3D: Yes
360 Reality Audio / MPEG H: Yes / Yes
Multichannel Stereo: Yes
Max Number of Processing (Preamp) Channels: 15.4

Sound Enhancements
Copper Plated Chassis: Yes
Power Transformer: Toroidal / EI: Yes / No
Current Feedback Topology: Yes
Hyper Dynamic Amplifier Modules (HDAM): Yes
Pure Direct: Yes
Gold plated RCA terminals: Yes
Clock Jitter Reducer: Yes
Audyssey: MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
Audyssey LFC: Yes
Dirac Live upgradability: Yes
Compressed Audio Enhancer: MDAX2: Yes

Network
HEOS Multi-room and Streaming: Yes
Bluetooth Re-transmit for Bluetooth headphones: Yes
Alexa / Google Voice Assistant / Apple HomePod: Yes / Yes / Yes
Network Audio Sharing: Yes
Lossy formats: MP3 / WMA / AAC: Yes / Yes / Yes
Lossless formats: FLAC / ALAC / WAV: Yes / Yes / Yes
Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24: Yes / Yes / Yes
DSD Audio Streaming: Yes (2.8/5.6MHz)
FLAC HD 192/24: Yes
WAV 192/24: Yes
ALAC 192/24: Yes
Gapless Playback: Yes (FLAC, WAV ,ALAC ,DSD)
AirPlay Audio Streaming: Yes (AirPlay2)
Internet radio: Yes (TuneIn)
Spotify: Yes (connect)
Pandora: Yes
SiriusXM: Yes
Amazon Music HD: Yes
Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / Soundcloud / Mood Mix: Yes (all)
Roon Tested: Yes
Compatible with Remote APP for Smart Phones: Marantz AVR Remote
Compatible with Remote APP for Tablets: Android / iOS / Amazon Kindle
Ethernet Ports: Yes
Wi-Fi: Yes
Bluetooth: Yes

HDMI
HDMI Inputs: Back / Front: 7 / No
HDCP2.3 support: Yes
HDMI Outputs: Main / Zone: 2 / 1
HDMI to HDMI Scaling: 1080P/4K to 8K
GUI Overlay on HDMI: Yes
HDMI 2.1: 8K/60Hz AB / 4K/120Hz AB: Yes / Yes
8K/60Hz AB / 4K/120Hz AB Pass-through In/Out: 7 / 2 (up to 40Gbps)
HDMI 2.0: 3D / 4K / CEC / ARC: Yes / Yes / Yes / Yes
Enhanced ARC: Yes
HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR: Yes / Yes / Yes / Yes / Yes
ALLM (Auto Low Latency Mode) Pass-through for gaming: Yes
Variable Refresh Rate / Quick Frame Transport: Yes / Yes
3D Signal Pass-Through: Yes
8K signal pass-through / scaling / GUI overlay: Yes / Yes / Yes
4K Signal Pass-Through / Scaling / GUI Overlay: Yes / Yes / Yes
HDMI pass-though in standby mode: Yes
Picture Adjust / Noise Reduction: No / No
CEC: Yes
DSD Audio Capability: Yes
Audio Return Channel: Yes
Auto LipSync: Yes

Multi-Room CI
HEOS Multi-Room Integrated: Yes
HEOS Link Compatibility: IR/ IP: Yes / Yes
Multi-Room Zones: 3
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: Yes (2ch) / Yes (2ch) / Yes / Yes
Zone Audio Output: Speaker / Preout: No / Yes
Zone HDMI Output from HDMI Source: Yes
IP Control / RS232 Control / Web Control / App Control: Yes / Yes / Yes / Yes
IR Flasher In: Yes
Marantz Remote Bus: Yes
DC Trigger Output: 2
HDMI Diagnostics: Yes

Others
Auto Speaker Setup by Microphone: Audyssey MultEQ XT32 or Dirac Live (upgrade)
Front Display: 2 line FLD + port hole OLED
Graphic User Interface - GUI: Modern HD GUI
GUI Languages: 9
Setup Assistent: Yes
Smart Select: Yes
Firmware Update by Network / USB: Yes / Yes
Variable Cross Over: Yes
Optimized Bass Redirection: Yes
Bass Sync: Yes
Auto Power off: Yes
Sleep Timer: Yes

Inputs Outputs
Composite In / Out: No / No
Component In / Out: No / No
HDMI In / Out: 7 / 3
Multi-Room Video Out: Video / HDMI: No / Yes
Analogue In / Out: 5 (1x XLR) / No
Phono (MM) In: Yes
Digital In: Optical / Coaxial: 2 / 2
Multi-Room Out: analog / digital: 2 / No
Multichannel Pre Out: Yes (17.4 RCA & 17.4 XLR)
Subwoofer Out: 4 (independent)
Speaker A / B: assignable pre out
Bi-amp drive: assignable pre out
Multi-Room Speaker Terminal: pre out
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB: No / No / No / No / Yes
USB Audio / Made for iPod / Made for iPhone: Yes / No / No
AM/FM Tuner: Yes

General
Metal Front Panel: Yes
System Remote Control: RC047SR
Pre-Programmed / Learnable / LCD Display: Yes / Yes / Yes
Power Consumption in W: 100
Standby Consumption in W: 0.2
CEC Standby Consumption in W: 0.5
Network Standby Consumption in W: Less than 2.0
Maximum Dimensions Antenna:Horizontal:(W x D x H) in inches: 17.4 x 19.8 x 7.4
Maximum Dimensions Antenna:Vertical :(W x D x H) in inches: 17.4 x 19.8 x 9.9
Maximum Dimensions W/o Antenna:(W x D x H) in inches: 17.4 x 19.0 x 7.4
Weight in lbs.: 37.0
What's in the box: Main unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, card board microphone stand, 2 External Detachable Antenna, AC cord
