Marantz MM7055 – 5 Channel Amplifier
Marantz
$1,499.00
(No reviews yet)
Write a Review
Marantz
Marantz MM7055 – 5 Channel Amplifier
MM7055
From its sculptured front panel to its high quality loudspeaker binding posts, the MM7055 five channel power amplifier brings Marantz sound quality to virtually any music or home theater system. Using technologies originally developed for the exclusive Marantz Reference Series, this flexible amplifier boasts many possible uses, all united by the singular quest for perfection that has long distinguished Marantz.
The MM7055 class A/B power amplifier produces 140 watts of high current output from each of its five channels. This is “real world” power, too, measured across the full audio bandwidth (20 Hz – 20 kHz) at 8 ohms with 0.08% Total Harmonic Distortion. Among other attributes, this means the MM7055 is capable of long- term power delivery into low impedance speakers.
A massive power supply includes a multiple-secondary EI-core transformer and over 65,000 μF of custom-designed energy storage capacity to meet the demands of today’s current hungry loudspeaker designs. Balanced inputs and single-ended RCA inputs are both supported, and audiophile grade, gold-plated four way binding posts insure tight connections to your choice of speaker wire.
The MM7055 includes input and output jacks for DC “trigger” pulses as well as RC-5 jacks for total remote control convenience, even with legacy Marantz products.
The chassis itself is heavy gauge steel for maximum isolation from external vibration as well as electromagnetic and radio frequency interference. And chassis depth is less than 141⁄2” so the MM7055 will fit quite nicely on a shelf, in a cabinet, or in a conventional system rack.
Features
- Porthole Display with Blue Illumination Accent
- 140W/ch (8 ohms), 170W (6 ohms) RMS Power (20Hz-20kHz)
- “Current Feedback” Amplifier Output Stage
- High Instantaneous Peak Current design
- Low Impedance Continuous Drive Capability
- Custom Sound Tuning
- Marantz Reference-Grade Filter Capacitors and High-Speed
- Output Transistors
- Audiophile grade, gold-plated four-way binding post speaker terminals insure tight connections to your choice of speaker wire.
- Flasher Input/DC Trigger In/Out/RC-5 Remote Control
- Output stages mounted on an extruded aluminum “thermal tunnel”for efficient heat dissipation.
- Ideal for a “5.1” home theater system, whether based on a moderately powered receiver or a surround sound processor.
- Meticulously tuned by the Marantz Sound Master for amazing performance with careful parts selection to create the Most Musical Sound in your home.
- Balanced XLR inputs and single-ended unbalanced RCA inputs are both supported, and you can choose either type of input for each channel, individually, for easy and flexible connectivity.
Details & Specifications
Amplifier Class: A/B
Number of Channels: 5
Current Feedback Topology: Yes
Discrete Amplification: Yes
Power Transformer: Large Capacity EI
Main Amplifier In: Balanced XLR & Unbalanced RCA for all 5 channels (Exclusive use by a selector switch.)
Source Direct: Steel
Variable X-over: Steel
Display Off: Blue LED Illumination off mode available
DC Triggers: 1 In / 1 Out
D-Bus Remote (RC-5) In/Out: 1 In /1 Out
Flasher In/IR Receiver In/Emitter out: 1/0/0
Voltage amplification level: 29dB
Rated Power Output @ 8Ω: 140W (5 channels driven 20Hz-20kHz, 0.08%)
Rated Power Output @ 6Ω: 170W (5 channels driven 20Hz-20kHz, 0.08%)
Maximum effective output power: 210w per channel @ 6Ω (from 1 kHz, two channels driven)
Output bandwidth (8 Ω load, 0.09 %): 5Hz–40kHz
Damping Factor: 100
Input sensitivity: 1.2V Unbalanced / 2.4V Balanced
Input Impedance: 22 kΩ Unbalanced / 30 kΩ Balanced
Signal to Noise Ratio: 105dB
Frequency Response @ (1 W, 8 Ω): 8Hz–100kHz(±3dB)
Front Panel: Aluminum/Glass-reinforced resin
Power Requirement: AC 120 V, 60 Hz
Supply Voltage: AC230V,50Hz
Power Consumption: 660W
Standby Power: 0.2W
Dimensions W x H x D: 17-3/8 x 7-3/16 x 15-1/8 in. (440 x 183 x 384mm)
Weight: 34.6 lb. / 15.7 kg.
Amplifier Class: AB
Warranty: 3 Year
