Marantz TT15S1 – Belt Drive Turntable
Marantz TT-15S1 Reference Belt Drive Turntable with Cartridge
Defined by its pristine sound, immaculate detailing, and superior quality cartridge, TT-15S1 reproduces immaculate high-fidelity.
- Low-resonance high-density acrylic chassis and platter
- Floating motor mount construction to reduce vibration
- Non-servo controlled AC motor
- Belt drive system with endless silicon belt for smooth platter rotation
- Anodized aluminum straight-type tonearm
- Magnetic-type anti-skating mechanism
- Fine adjustable counterweight
- Solid aluminum three-point support feet
- Clearaudio Virtuoso MM cartridge
- Isolated motor
- “Clever Clamp” by Souther Engineering
- Manual operation
- Meticulously tuned by the Marantz Sound Master for amazing performance
- 5-year warranty (30-day cartridge & needle)
Highlights & Key Technologies
Incredible Materials and Incredible Sound
Masterfully crafted, and carefully curated with hand-selected materials, the TT-15S1 is as impeccable as they come, delivering the most authentic format with unprecedented clarity.
Designed to Perform
The TT-15S1 is more than just incredible to look at; it has been expertly engineered to provide the perfect platform for your records to sound their best. This includes a low-resonance high-density acrylic chassis and platter.
Sound Master Tuned
The Marantz Sound Master meticulously tuned TT-15S1 for amazing performance with careful parts selection to create the Most Musical Sound in your home.
Floating Motor
To avoid any performance-limiting chassis vibration, the TT-1551’s precision motor system has been designed to ‘float’ rather than sit on the acrylic chassis.
Belt Drive System
TT-1551 belt drive system features an endless silicon belt for the smoothest possible rotation of the platter, ensuring precision timing and sensational listening.
Details & Specifications
TURNTABLE
RPM: 33 1/3 rpm, 45 rpm
Drive system: Belt drive system (Silicon Belt)
Turntable: High density acrylic
Turntable depth: 28 mm
Platter height: 1.2"
RPM deviation: ±0.2%
Speed variation: +/- 0.2%
S/N ratio: 80 dB
S/N Ratio MM/MC: 80dB/-
TONE ARM
Arm type: 2 point radial tone arm
Effective length: 239mm
Overhang: 17mm
Stylus pressure adjustable range: 0-5g (1 Graduation = 0.1g)
Compatible cartridge weight: 3-18g (excluding head shell)
INCLUDED CARTRIDGE (CLEARAUDIO VIRTUOSO MM)
Frequency response: 20Hz - 20 kHz
Output voltage (1kHz, 5cm/s): ≈3.6 mV
Rated output (1kHz, 5m/s): 3.6mV
Channel separation: > 30 dB
Channel balance: < 0.2 dB
Recommended stylus pressure: 2.2 g
Impedance: 0.66 kΩ
Cantilever: Aluminum
Cartridge weight: 6.0 g
FEATURES
Motor: Non Servo AC Motor
Drive system: Belt Drive (Silicon Belt)
Operation: Manual
Speed: 33 1/3 & 45 rpm
Stylus: MM (Moving Magnet)
IN/OUTPUTS
Line output: 2 channel
GENERAL
Color: Transparent White
Power supply: AC 120V, 60 Hz
Power Consumption: 5W
Dimensions W x H x D: 16.5" x 5.4" x 14.2" (w/o Tonearm)
Dimensions: Width 440mm x depth 350mm x height 110mm (Excluding tone arm)
Weight: 19.6 lbs (w/o Tonearm & motor)
Net weight: 8.9kg (including tone arm/motor)
Model / SKU: TT15S1
UPC / EAN: 699927840051
