RBH Signature Reference 661-SF/R – Stand Mount Bookshelf Speaker

RBH Sound 661-SF/R – LCR Stand Mount Bookshelf Speaker

Like the reference version of its sibling, the 661-SF, the 661-SF/R can be used for high-fidelity 2-channel stereo systems and home theater systems alike. As a stereo pair, the 661-SF/R delivers a musical experience as the recording artist originally intended. For home theater, the 661-SF/R's dual 6½-inch reference aluminum cone woofers and AMT tweeter deliver crystal-clear dialog and vibrant sound effects with superb clarity and acoustic performance. These reference drivers provide extended frequency response, greater power handling, and improved dynamic range. The 661-SF/R is versatile enough to be used for nearly any main or effect channel in a multi-channel surround sound system.

• (1) 1.38" x 1" (35mm x 25mm) RBH Reference AMT tweeter
• (2) 6½" cast aluminum basket, aluminum cone woofers with solid aluminum phase plugs, silver or black-anodized
• Dual rear ported cabinet
• 6 ohm impedance
• 2700 Hz crossover, 24 dB/Octave
• 50–40,000 Hz (±3dB) Frequency Response
• 91 dB Sensitivity
• Designed, Engineered, Tested and Assembled in USA from American and Imported Parts
• 10 Year Limited Warranty

Highlights & Key Technologies

RBH Sound Reference Driver Package
The 661-SF/R upgrades the 661-SF by replacing the signature drivers with the RBH Sound Reference Driver package. This upgrade includes the RBH Reference AMT tweeter — measuring 1.38" x 1" (35mm x 25mm) — and dual RBH Reference 6½-inch cast aluminum basket aluminum cone woofers with solid aluminum phase plugs, available in silver or black-anodized. An enhanced crossover circuit is also included. Together, these reference drivers provide extended frequency response, greater power handling, and improved dynamic range relative to the standard 661-SF.

MTM Configuration & Versatility
The 661-SF/R features a mid-tweeter-mid (MTM) configuration combining dual 6½-inch reference aluminum cone woofers with a centrally positioned AMT tweeter with tweeter protection. The two-way crossover is set at 2700 Hz with a 24 dB/Octave slope. This configuration sets the standard for home theater sound, combining the power of multiple drivers for greater dynamic response and directivity. The 661-SF/R is versatile enough to serve as left and right main channels, a center channel, or surround channels in a multi-channel surround sound system.

Vented HDF Cabinet
The 661-SF/R cabinet is constructed from ¾-inch High Density Fiberboard (HDF) with heavy internal bracing, individually hand assembled and tested in the USA, and is available in satin black or white. The cabinet features dual rear ports. A magnetically attached white or black high quality fabric grille with a ½" MDF frame is included.

SF Series Compatibility
The 661-SF/R provides timbre-matched options for multi-channel sound across all freestanding, bookshelf, on-wall, and in-wall products in the SF, SV, and SI Series.

Details & Specifications

MODEL INFORMATION
Model: 661-SF/R
Series: Signature Reference Series | Freestanding Speaker
System Type: Vented / LCR 2-way Speaker

DRIVE UNITS
(2) 6-1/2" (165mm) cast aluminum basket, aluminum cone (silver or black-anodized), with solid aluminum phase plug
(1) 1.38" x 1" (35mm x 25mm) AMT Tweeter

PERFORMANCE
Frequency Response: 50–40k Hz (±3dB)
Sensitivity: 91 dB (2.83V @ 1 Meter)
Recommended Power: 75–250 Watts
Impedance: 6 Ohms
Tweeter Protection: Yes

CROSSOVER
Crossover Frequency: 2700 Hz
Crossover Slope: 24 dB/Octave

CABINET
Cabinet Material: High Density Fiberboard (HDF), ¾" construction, heavy internal bracing
Cabinet Color: Satin Black or White
Grille: White or Black high quality fabric, ½" MDF frame, magnetically attached

PHYSICAL SPECIFICATIONS
Finished Dimensions: 7-3/4" x 22-3/8" x 12-3/8" (197 x 569 x 315mm)
Weight: 21 lbs (9.53 kg)

WARRANTY
*10 Year Limited

ORIGIN
Designed, Engineered, Tested and Assembled in USA from American and Imported Parts
